DMN3404L
Maximum Ratings (@T A = +25°C, unless otherwise specified.)
Characteristic
Drain-Source Voltage (Note 6 & 7)
Gate-Source Voltage
Symbol
V DSS
V GSS
Value
30
±20
Units
V
V
Continuous Drain Current (Note 6) V GS = 10V
Continuous Drain Current (Note 7) V GS = 10V
Continuous Drain Current (Note 7) V GS = 4.5V
Continuous Drain Current (Note 7) V GS = 3V
Pulsed Drain Current
Steady
State
Steady
State
Steady
State
Steady
State
T A = -40°C
T A = +25°C
T A = +85°C
T A = -40°C
T A = +25°C
T A = +85°C
T A = -40°C
T A = +25°C
T A = +85°C
T A = -40°C
T A = +25°C
T A = +85°C
I D
I D
I D
I D
I DM
4.6
4.2
3.0
6.2
5.8
4.0
5.2
4.8
3.2
2.2
2.0
1.0
30
A
A
A
A
A
Thermal Characteristics
Characteristic
Power Dissipation (Note 6)
Thermal Resistance, Junction to Ambient @T A = +25°C
Power Dissipation (Note 7)
Thermal Resistance, Junction to Ambient @T A = +25°C
Operating and Storage Temperature Range
Symbol
P D
R θ JA
P D
R θ JA
T J, T STG
Value
0.72
173
1.4
90
-55 to +150
Unit
W
°C/W
W
°C/W
°C
Notes:
6. Device mounted on FR-4 substrate PC board, 2oz copper, with minimum recommended pad layout.
7. Device mounted on FR-4 substrate PC board, 2oz copper, with thermal bias to bottom layer 1inch square copper plate.
DMN3404L
Document number: DS31787 Rev. 8 - 2
2 of 8
www.diodes.com
August 2013
? Diodes Incorporated
